Product Details:
Place of Origin: China
Brand Name: Briture
Certification: CE、ISO
Model Number: PEEK Fiber
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: USD200-300/KGS
Packaging Details: 2 kgs net each roll
Delivery Time: 9-15work days
Payment Terms: L/C, T/T
Supply Ability: 3000MT/year

Polyetheretherketone (PEEK) Fiber For Composite Materials For Structural Components Required For Weaponry

Description
Product Name: PEEK Fiber Monofilament Diameter: 0.06,0.07.0.10,0.15,0.20~0.90,1.00
Multifilament Types (D/F) +/-20D: 150/30,200/30,250/60,300/60~1000/ 120
High Light:

High Temperature Creep Resistance Polyetheretherketone Fiber

,

Composite Materials PEEK Fiber

,

Weaponry Structural Components PEEK Fiber

Polyetheretherketone (PEEK) Fiber For Composite Materials For Structural Components Required For Weaponry



Properties:
PEEK specialty fiber is produced by high temperature melt spinning of PEEK resin.
1. UL temperature index 250℃.
2. Purity resin up to 94MPa, fiber enhanced up to 210MPa.
3. Except sulfuric acid, almost insoluble in any regular chemical reagents.
4. Resistant to 109 rad, equivalent nuclear reactor radiation intensity.
5. Especially high temperature creep resistance, equivalent nylon normal temperature
endurance at 150℃,
6. Can meet 94V-1 of 0.3mm thick, can meet 94V-0 of 1.5mm thick,
7. Only produce H2O and CO2 when fully burned, does not produce any toxic gas.
8. There is still enough endurance at more than 200℃.
9. Monofilament rupture strength about 25~40cN/tex,multifilament up to 65 cN/tex.
10. Elongation 20%~40%
11. Modulus 3~6GPa,
12. LOI value 35,
13. Melting point 334~343℃, Long-term use temperature of 250℃.

Specification:
Available Monofilament Diameter (mm)+/-0.03
0.06 0.07 0.10 0.15 0.20 0.25 0.28 0.30 0.35 0.38
0.40 0.45 0.50 0.55 0.60 0.70 0.80 0.90 1.00 /





Available Multifilament Types (D/F) +/-20D
150/30 200/30 250/60 300/60 400/60 450/60
500/ 120 600/ 120 800/ 120 900/ 120 1000/ 120 /





Application:

PEEK fiber is mainly used in aerospace, composite materials for structural components required for weaponry, braided sheath for aerospace high-performance wire and cable, and dry canvas for paper

making machinery in civil fields, heat-resistant filter cloth, Heat resistant and corrosion resistant textile tape, Composite materials (mixed with glass fiber, carbon fiber), high temperature resistant materials for the energy industry
