Product Details:
Place of Origin: China
Brand Name: Briture
Certification: CE、ISO
Model Number: PEEK Fiber
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: USD200-300/KGS
Packaging Details: 2 kgs net each roll
Delivery Time: 9-15work days
Payment Terms: L/C, T/T
Supply Ability: 3000MT/year

UL Temperature Index 250℃ Polyetheretherketone (PEEK) Fiber For Dry Canvas For Paper Making Machinery In Civil Fields

Description
Available Monofilament Diameter: 0.06-1.00 Mm UL Temperature Index: 250℃
Packing: Roll Material: Wholly Aromatic Fiber With The Presence Of Ether Bonds And Ketone Bonds
High Temperature Resistance: UL Temperature Index 250℃ High Strength: Purity Resin Up To 94MPa, Fiber Enhanced Up To 210MPa
Chemical Resistance: Except Sulfuric Acid, Almost Insoluble In Any Regular Chemical Reagents Irradiation Resistant: Resistant To 109 Rad, Equivalent Nuclear Reactor Radiation Intensity
Modulus: 3~6GPa LOI Value: 35
High Light:

PEEK Fiber Roll

,

Dry Canvas PEEK Fiber

,

Paper Making Polyetheretherketone Fiber

UL Temperature Index 250℃ Polyetheretherketone (PEEK) Fiber For dry canvas for Paper Making Machinery In Civil Fields



Properties:
PEEK specialty fiber is produced by high temperature melt spinning of PEEK resin.


1. Creep resistance: especially high temperature creep resistance, equivalent nylon normal temperature
endurance at 150℃,
2. High flame retardancy: can meet 94V-1 of 0.3mm thick, can meet 94V-0 of 1.5mm thick,
3. Only produce H2O and CO2 when fully burned, does not produce any toxic gas.
4. Excellent high temperature hydrolysis resistance: there is still enough endurance at more than 200℃.
5. High tensile strength of 400 ~ 700MPa: monofilament rupture strength about 25~40cN/tex,
multifilament up to 65 cN/tex.
6. Elongation 20%~40%
7. Melting point 334~343℃, Long-term use temperature of 250℃.

Specification:
Available Monofilament Diameter (mm)+/-0.03
0.06 0.07 0.10 0.15 0.20 0.25 0.28 0.30 0.35 0.38
0.40 0.45 0.50 0.55 0.60 0.70 0.80 0.90 1.00 /





Available Multifilament Types (D/F) +/-20D
150/30 200/30 250/60 300/60 400/60 450/60
500/ 120 600/ 120 800/ 120 900/ 120 1000/ 120 /





Application:

aerospace composite materials for structural components required for weaponry
braided sheath for aerospace high-performance wire and cable

dry canvas for paper making machinery in civil fields

heat-resistant filter cloth Heat resistant and corrosion resistant textile tape
Composite materials (mixed with glass fiber, carbon fiber), high temperature resistant materials for the energy industry
