White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement

Certification
China Briture Co., Ltd. certification
China Briture Co., Ltd. certification
I'm Online Chat Now

White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement

White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement
White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement

Large Image :  White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement

Product Details:
Place of Origin: China
Brand Name: Briture
Certification: ISO /SGS/CE certificate
Model Number: Twist 51mm
Payment & Shipping Terms:
Minimum Order Quantity: 1000kgs
Price: USD2.25-USD2.6/KG
Packaging Details: 1kg Per PE Bag, 10kg Per Woven Bag
Delivery Time: 2-3weeks
Supply Ability: 2000MT per year

White 51/54mm PP Macro Fiber Twist Bunchy Fiber For Concrete Reinforcement

Description
Raw Material: 100% Virgin Polypropylene Product Name: PP Bunchy Twist Fiber
Other Name: Polypropylene Fibre/PP Fibre Fiber Form: Twist /Bunchy
Color: White /Grey Fiber Length: 48mm, 50mm, 51mm,54mm As Per Request
Application: Concrete/Cement Reinforcement Packing: 1kg Per PE Bag, 10kg Per Woven Bag
High Light:

Concrete Reinforcement PP Macro Fiber

,

Twist Bunchy PP Macro Fiber

,

54mm Concrete Polypropylene Fibers


Polypropylene Fiber Twist Bunchy Form

Product Description

Briture Polypropylene Fiber (PP Fiber) is made from 100% virgin PP granular, after extruding from different mould and technology, we can get 4 different types of fiber, including Monofilament form, Fibrillated Mesh form, Twisted Bunchy and Wave form with different size. These fiber can improve the reinforcement of mortar or concrete performance effectively to make them strong and protect the projects.



Introduction:

1. This fiber is used to instead of steel fiber for reinforcement to cement concrete. Compared with steel fiber, it has the advantage of easy dispersing and blending, no damage to the mixing equipment, etc

2. The rigid polymer fiber is used polypropylene as its raw material, produced the rough surface treatment by special parallel thread extruding & twisting process. It has high break strength, better dispersion and strong combining ability, will be widely used to instead of steel fiber to reinforce the cement concrete and crack-resistant.

Apply Instruction:

1. Ration design of the fiber concrete: Generally the recommended amount to add to the concrete is more than 2.7kg per m3(volume ratio is 0.3%), reinforcement adding amount is 5.5kg, Compared with adding 47kg of steel fibre, 5.4kg polymer fiber has the same volume ratio to the concrete.

2. Length: 54mm for common crack-resistant requirement.

3. Matching Ratio: Usually, it is no need to Change the matching ratio of the concrete. Considering the requirement of fissure-resistant, the polymer fiber is recommend to combine with the PP fiber mesh form with the volume ratio of 1:1 (0.9kg fiber-mesh to per m3 of cement concrete).

4. Mixer Adoption: Double-axle horizontal compelling mixer is priority.

5. Mixing process: Crushed stones, fibers and sands are put into the mixer in succession. After stirring for two minutes, fiber will fully spread and then add cement and water and stir normally. The addition of materials also can be put into as common concrete, but the stirring time should be properly prolonged to make fiber completely mixed

6. Shaping & Maintenance: There is no special requirement, may along the vibrating time for 30s, The maintenance of the fiber concrete should be done same as the normal concrete.

Application:

  • Industrial and residential floor
  • Whitetoppings, bridge decks and pavements
  • Thin walled pre-cast (septic tanks, vaults, walls, etc.)
  • Mass concrete

Specification

Raw Material

Polypropylene

Fiber Type

Twisted Bunchy form

Length (mm)

40/48/50/51/54 as per request

Diameter (mm)

0.3+/-0.05

Tentile Strength (Mpa)

>560

Elastic Modulus (Mpa)

>5000

Break tesile ratio (%)

>15

Density

0.91

Dosage rates will vary depending upon the reinforcing requirements and can range from 2kg/m³ to 5 kg/m³

Product & Packing

Packing one:

1).: 500g, or 1kg net per PE bag

2).: 10kgs per plastic woven bag

3).: 6000kgs/1X20`FCL without pallet

4).: 13000kgs/1X40`HQ without pallet



Packing two:

1).: 500g or 1kg net per water soluble paper bag.

2).: 10kgs per carton

3).: 450cartons/1X20`FCL without pallet

4).: 1120cartons/1X40`HQ without pallet
