Product Details:
|
Steel Fiber Length (mm): | 35-60 | Steel Fiber Diameter (mm): | 0.75 |
---|---|---|---|
Steel Fiber Draw Ratio (L/D): | 80;45;65 | Steel Fiber Tensile Strength (mpa): | 1000 Min. |
Steel Fiber Product Name: | Steel Fiber | Steel Fiber Fiber Type: | Single Or In Rows |
Steel Fiber Feature: | Greatly Improve Concrete Bonding And Tensile Strength | ||
Highlight: | Floor And Tunnelling Steel Fiber,1000MPA Steel Fiber |
Product Description:
For many years, steel fiber reinforced concrete has primarily been used in non-structural applications like industrial flooring and shotcrete. This is due to the fact that with traditional fibre dosage rates, steel fiber reinforced concrete shows a semi-ductile, strain softening post-cracking behaviour. Due to the development of new, better performing fibres, the scope of applications for steel fiber reinforced concrete has been significantly widened.Today, steel fibres can be used as the sole reinforcement or combined with traditional reinforcement such as rebar, wire mesh or pre-stressing elements in numerous applications.In all these applications, the use of steel fibers helps to control and reduce shrinkage cracking and allows the steel fibre reinforced concrete element to reach full ductility even though plain concrete is a brittle material.
Function:
1. Steel Fiber can improve the crack resistance of concrete and reduce the damage to concrete
2. Steel Fiber can improve the mechanical properties of concrete
3. Steel Fiber can improve the strength of concrete
4. Steel Fiber can reduce the risk of cracks in concrete
5. Steel Fiber can provide excellent load stability and durability
Advantage:
1. Steel fiber for high temperature firebrick
2. High intensity steel fiber
3. High anti-bending steel fiber
4. High solid riveting force steel fiber
5. Anti-compressive steel fiber
6. Good comprehensive effect steel fiber
Application:
Because of its high tensile strength, good toughness and low price, compared with other shapes of steel fibers, its tensile strength, compressive strength and flexural strength have been greatly improved, which is suitable for some key anti-seismic and anti riot structural projects.
Ready mixed concrete | Precast concrete |
Self Compacting Concrete | Shortcrete |
Concrete | Flooring,Roads |
Overlays | Structural |
highway slope protection bridges,
|
tunnels, railway |
airports,ports |
Specification:
Model | Length (mm) | Diameter (mm) | Draw Ratio (L/D) | Tensile Strength (mpa) |
80/60 | 60 | 0.75 | 80 | 1000 min. |
45/35 | 35 | 0.75 | 45 | 1000 min. |
65/35 | 35 | 0.55 | 65 | 1000 min. |
Packing:
The packing of steel fiber is 20kgs net each bag, 24tons in a 20GP
